Mecanum Wheel Pair - 48mm

Mecanum Wheel Pair - 48mm
Mecanum Wheel Pair - 48mm Mecanum Wheel Pair - 48mm Mecanum Wheel Pair - 48mm
Product Code: G626CA698016A4
Reward Points: 0
Availability: 450
Price: $6.50

5 or more $6.00
20 or more $5.50
   - OR -
Mecanum wheels allow your robot to not only travel forward and backward, but also sideways! Nine rollers set on a 45° rotational axis parallel to the main rotational axis of the wheel enable a broad a range of movement. Rotating all four wheels in the same direction causes forward or backward movement, rotating the wheels on one side in an opposite direction to those on the other side causes the vehicle to rotate, and rotating the wheels on one diagonal in the opposite direction to those on the other diagonal causes side-to-side movement.

These mecanum wheels come in pair (1x left, 1x right). They are about 48mm in overall diameter and weight about 50g total, you will need 3mm wheel-moter adapter to connect with motor.



Specifications:

  • Materials: Rubber and ABS
  • Diameter: 48mm
  • Width: 25mm
  • Wheel Roller: 9 wheels
  • Weight: 50g/pair
