TOSR196 - 12 Channel Smartphone Bluetooth Relay - (Password/Momentary/Latching)
20 or more $60.00
TOSR196 Bluetooth Relay board support both Andorid and iOS and it has password. It’s a convenient and easy-to-use product that be used to control any electrical equipments. You may wish to pair with a mobile phone. Open the APP->Connect Device, use your phone to search for a new Bluetooth device. The module will appear as "BT Bee-BLE". Connect it, and then you can control the relays ON/OFF. The communication way also can be changed easily. Remove the Bluetooth Bee module instead with a WiFiBee, it becomes a WIFI relay.
TOSR196 supports password. You can set each channel to latching or momentary output. This relay board provides four volt free contact relay outputs with a current rating of up to 10Amp each. one DS18B20 temperature sensor port. The module is powered from a 5VDC power supply. The DC input jack is 2.1mm with positive core polarity, The relays are SPDT types. If you want power it with DC12V or 24V, you just need a 12V/24V-5V DC converter.
Note: Relay board default password is: 123456
Note: Please remove the Bluetooth module when you use USB connection.
Smartphone APP:
We also provide FREE Android/iOS App. You can control your device by your phone very easily.
How to reset the password:
- Remove the DC5V power
- Press the Password reset button and hold on
- Power on the board
- Yellow LED 'L' turn on
- Release the Password reset button, Password reset to "123456"
Commands
The TOSR196 operates with an easy to use command set as described in the table below.
TOSR196 Baud rate : 9600
Features:
- Working voltage: 5VDC
- Bluetooth 4.0
- Android and iOS supported
- Dimension: 150x98x17.2(mm)
- Standby Current 10mA/5VDC
- Current rating of up to 10 Amp.
- Each channel can set to Latching or momentary ouput
- Password supported
Documents:
